PowerQUAD^™ 20 Gallon NED Vacuum Kit w/ 2" Inlet

Name: PowerQUAD™ 20 Gallon NED Vacuum Kit w/ 2" Inlet
Brand: Guardair
SKU: PQ20C200NED
Price: 2566.33 USD
Availability: InStock

1 20

Part Number: PQ20C200NED

NED Wet/Dry Vacuum: 20-gallon pneumatic kit with 2" inlet controls nuisance static during cleanup
Static-Conductive System: Bonded components and conductive hoses dissipate stray charges through the vacuum
Quiet Operation: Runs at 88 dBA or less to reduce industrial cleanup noise

See more details

$2,566.33

Product variants

Quantity

View full details

Overview

The Guardair PowerQUAD 20-Gallon NED Vacuum Kit (PQ20C200NED) is a compressed-air-powered wet/dry vacuum with a 2" inlet used to pick up chips, dust, debris, liquids, and sludge where nuisance static electricity is a concern. Electrically conductive components, a static-conductive vacuum hose, and a static-conductive air supply hose help dissipate stray charges through the system. Three injector nozzle sets let crews balance compressed-air use and suction, while the rugged 2-stage multi-venturi engine has no electric motor, rotating parts, or power cord. NED models are not certified for hazardous locations. Proudly assembled in the USA.

View the PowerQUAD Vacuum Performance table.

Resources

Features

NED Wet/Dry Vacuum: 20-gallon pneumatic kit with 2" inlet controls nuisance static during cleanup
Static-Conductive System: Bonded components and conductive hoses dissipate stray charges through the vacuum
Quiet Operation: Runs at 88 dBA or less to reduce industrial cleanup noise
Configurable Performance: Three injector nozzle sets provide flexible vacuum performance while helping conserve compressed air
Energy-Efficient Power: Uses up to 70% less compressed air while maintaining strong vacuum performance
Wet/Dry Ready: Liquid shutoff supports collection of chips, dust, debris, liquids, and sludge

Includes

(1) PowerQUAD 20-Gallon NED Vacuum Generating Head w 2" Vacuum Inlet
(1) Standard Cartridge Filter
(1) 20/30/55 Gal Wire Cage Coalescing Filter
(1) Air Supply Shut-Off Valve w/ 1/2" FNPT
(1) 1/2" x 12' Static Conductive Air Supply Hose w/ 1/2" MNPT Swivel connectors
(1) 2" x 10' Static Conductive Vacuum Hose
(1) Heavy-Duty, 18-Gauge, 20-Gallon Steel Drum with a Standard 2" Bung Opening
(1) 4' Steel Wand w/ 12" Wide Aluminum Floor Tool
(1) 24" Aluminum Crevice Tool
(1) Drum Dolly w/ (4) 3" Diameter Steel Swivel Casters

Typical Applications

Industrial vacuum for vacuuming up chips, dust, debris, liquids or sludge
For use were static electricity is present
Continuous duty applications

Shipping & Returns

Lead time: 8 Days. Not eligible for free shipping.

Non-returnable.

Read the full Shipping & Return policy here.

⚠️ WARNING: Cancer and Reproductive Harm - P65warnings.ca.gov

Warranty

All PowerQUAD™ vacuums feature our exclusive GUARDAIR FOREVER WARRANTY.

How do PowerQUAD compressed air-powered vacuums work?

PowerQUAD vacuums use compressed air to create low pressure, generating vacuum flow through a venturi effect for efficient suction without needing an electric motor.

What are the advantages of compressed air-powered vacuums over electric vacuums?

Compressed air-powered vacuums avoid motor burnout, eliminate electrical hazards, reduce Total Cost of Ownership, and offer higher suction power, especially for heavy materials.

What is the difference between Vacuum Flow and Vacuum Lift?

Vacuum Flow measures air volume through the hose, impacting debris movement, while Vacuum Lift measures the height a vacuum can lift materials, key for deep cleaning.

How do vacuums generate static electricity?

Static electricity is created as air moves over the vacuum hose’s internal surface, influenced by air composition, humidity, and material type.

What size air compressor do I need to operate a PowerQUAD vacuum effectively?

For optimal performance, PowerQUAD vacuums typically require an air compressor capable of delivering 4 cubic feet per minute (cfm) per horsepower (HP). For example, a 50 HP compressor will provide about 200 cfm, ideal for continuous operation. Check the PowerQUAD specifications to match your setup accurately.

Can I use any steel drum with my PowerQUAD vacuum generating head?

No. PowerQUAD vacuum generating heads produce extremely high head. Generating vacuum lift of up to 255 inches of H2O running on 80-90 psi of compressed air, they have been known to implode. See the "Specifications" tab for the minimum required steel drum gauge.

Does Guardair offer HEPA and ULPA filters for PowerQUAD vacuums?

Yes, Guardair provides HEPA and ULPA filters for PowerQUAD vacuums, alongside standard filters, to support a variety of cleaning needs.

Part Number	Drum Capacity (gal)	Vacuum Hose ID (in)	Compressed Air Inlet (in)	Compressed Air Usage (cfm)	Vacuum Flow (cfm)	Vacuum Lift (in H₂0)	Noise Level (dBA)	Min. Size Air Compressor (hp)	Min. Steel Drum (Gauge)	Dimensions (L" x W" x H")	Weight (lbs)
PQ20C150NED	20	1.5	1/2	20 - 40 - 60	92 - 118 - 130	126 - 225 - 250	82 - 85	4.4 - 13.3	18	24 X 24 X 36	76
PQ20C200NED	20	2	1/2	20 - 40 - 60	110 - 140 - 150	122 - 215 - 250	82 - 85	4.4 - 13.3	18	24 X 24 X 36	76
PQ30C150NED	30	1.5	1/2	20 - 40 - 60	92 - 118 - 130	126 - 225 - 250	82 - 85	4.4 - 13.3	18	24 X 24 X 48.5	80
PQ30C200NED	30	2	1/2	20 - 40 - 60	110 - 140 - 150	122 - 215 - 250	85 - 88	4.4 - 13.3	18	24 X 24 X 48.5	80
PQ55C150NED	55	1.5	1/2	20 - 40 - 60	92 - 118 - 130	126 - 225 - 250	82 - 85	4.4 - 13.3	19	28 X 28 X 48.5	95
PQ55C200NED	55	2	1/2	20 - 40 - 60	110 - 140 - 150	122 - 215 - 250	85 - 88	4.4 - 13.3	19	28 X 28 X 48.5	95
